Stark RS 105 rotary tiller
€1,020.00
Available, delivery time: 1-2 weeks
Description
Stark RS 105 rotary tiller
Stark RS105 - compact rotary tiller with 1.05 m working width for tractors from ~20 hp
TheStark RS105 is a robustTiller for farmyards, horticulture and market gardening, fruit growing/viticulture and grassland maintenance. With1.05 m working width it prepares seedbeds in a single pass, breaks up crusted soil and evenly mixes in crop residues or green manure.Three-point cat. I,PTO shaft 540 rpm and a lateral drive in an oil bath ensure reliable power transmission and a long service life.
Your advantages at a glance
- Fine seedbed in one pass: Intensive crushing and mixing of the topsoil.
- Simple depth control: stepless Adjustment via side skids andSpring-loaded tailgate for a uniform working pattern.
- Robust technology: Lateral drive in oil bath, solid main frame, maintenance-friendly bearings.
- Practical & safe: Complete protective cover, stone guard andPTO cover.
- Universal on the tractor: Three-point cat. Irecommended is a cardan shaft withSlipping clutch.
Typical areas of application
- Seedbed preparation in horticulture and arable farming
- Incorporating green manure, compost and mulch
- Breaking up hardened surfaces after rain/overflow
- Maintenance of beds, row and fruit crops
Technical data (RS105)
| Working width | 1,050 mm |
| Cultivation | Three-point cat. I |
| PTO shaft | 540 rpm (PTO shaft recommended) |
| Drive | Lateral oil bath drive |
| Knife assembly | approx.24 C-knife (depending on model), hardened |
| Working depth | until approx.16-18 cm (via skids/tailgate) |
| Tractor power | from approx.20-30 HP recommended |
| Dead weight | approx.180-210 kg (depending on equipment) |
Note: Values may vary slightly depending on the year of manufacture/equipment.
Scope of delivery
- TillerStark RS105 With protective cover and side skids
- Operating & maintenance instructions
Accessories (optional)
- PTO drive shaft with slipping clutch
- Spare blade set (C-blade)
Practical & safety instructions
- Check blade condition, belt/drive and screw connections before use; keep protective covers closed.
- Reach milling depth in several shallower passes; remove stones/roots beforehand.
- Observe tractor stand safety; never place persons in the danger zone.
Why the RS105? Compact 1.05 m working width, robust oil bath technology and finely adjustable working depth - the economical all-round tiller for professional soil cultivation on small to medium-sized areas.
