Mini shredder 300 x 300mm

Description

Mini shredder 300 x 300mm

Fully demountable (bolted) construction
one drive shaft
Working area 300x300 mm
Continuous fixing holes
Working tools made from wear-resistant steel



The shredder is equipped with a unique spring-loaded counter-blade clamping system that enables thorough cleaning of the space between the cutting blades.



Technical specifications
Recommended motor power: 5.5 kW
Knife diameter: 140 mm
Blade thickness: 10 mm
Blade tooth height: 15 mm
Number of shredding knives: 2 pcs
Number of knives on the shaft: 13 pcs.
Dimensions of the working chamber: 300 x 300 mm
Gear diameter: 116 mm
Weight of the mechanism: 95 kg
