Linhai ATV 500 Promax – Powerful ATV with 34 hp | Off-road & Work
Linhai
€4,445.38
Product number:
SW14650
Description
Linhai ATV 500 Promax – Powerful ATV with 34 hp | Off-road & Work
Linhai ATV 500 Promax - Powerful, robust and versatile
TheLinhai ATV 500 Promax combines powerful performance with modern driving comfort, making it the ideal companion for demanding off-road routes, agricultural work or leisure adventures. With its 34 hp, water-cooled engine and reliable 2WD/4WD switchover, it offers maximum control and stability at all times.
Highlights
- 34 hp engine power
- Robust McPherson suspension for precise handling
- Grippy off-road tyres for any terrain
- Comfortable ergonomic sitting position
- Ideal for work, leisure and difficult surfaces
Technical data
| Motorisation | |
|---|---|
| Model | LH188MR-A |
| Motor type | Single-cylinder, 4-stroke, water-cooled |
| Displacement | 493 cm³ |
| Bore x stroke | 87.5 mm x 82 mm |
| Rated power | 24/6500 rpm |
| Performance | 32.6 HP |
| Maximum speed | 60 km/h |
| Max. Torque | 38.8 Nm / 5500 rpm |
| Fuel system | EFI (fuel injection) |
| Gearbox | H-L-N-R |
| Starting system | Electric starter |
| Drive system | 2WD/4WD |
| Dimensions & weight | |
| Size (LxWxH) | 2120 x 1185 x 1270 mm |
| Wheelbase | 1280 mm |
| Ground clearance | 253 mm |
| Dead weight | 355 kg |
| Tank volume | 12,5 L |
| Tyres & Chassis | |
| Front tyres | AT25×8-12 |
| Rear tyres | AT25×10-12 |
| Front brakes | Hydraulic disc |
| Rear brakes | Hydraulic disc |
| Front suspension | McPherson independent suspension |
| Rear suspension | Twin A-arm independent suspension |
| Optional accessories | |
| Power steering, cable winch, heated handles, backrest, trailer coupling, cover | |
| Authorisation | |
| CE / T3a / T3b | |
TheLinhai ATV 500 Promax is the perfect choice if you are looking for a powerful, reliable and versatile ATV that is equally at home off-road and in everyday use.
