Hisun Guardian 400L – 400cc ATV 4x4 | High Payload | LED | EFI | Top All-Rounder

Hisun Guardian 400L - more power, more space, more possibilities

TheHisun Guardian 400L is the perfect choice for anyone looking for a powerful, versatile and reliable ATV with extended transport capacity. With its 400 cc engine, powerful 4x4 drive and robust construction, it is ideal for farm work, hunting, forestry, company grounds and demanding outdoor adventures.

Maximum versatility thanks to large load compartment

The Guardian 400L offers an extended rear area that provides additional load capacity. Perfect for tools, materials, luggage or equipment - ideal for professional and private use.

Modern features for maximum comfort

• 7" LCD display for clear and intuitive display of all driving data
• Keyless start system for modern operation
• Ergonomic switches - Pleasant, precise, well thought out
• Real LED lighting with strong light image
• Fast motor access thanks to removable cover

Standard equipment - everything a professional needs

• Ignition with key
• Handlebar protection
• Backrest (front passenger)
• Aluminium rims
• LED lighting system
• Underride guard
• Front and rear trailer coupling

Optional accessories

• Cable winch 1130 kg
• Luggage carrier front & rear
• Power steering
• Colour package
• Air suspension

Technical data - Hisun Guardian 400L

Engine

• Type: Single-cylinder 4-stroke SOHC
• cubic capacity: 400 cc
• Performance: 23 kW / 7000 rpm
• Torque: 32 Nm / 6000 rpm
• Compression: 10,39 : 1
• fuel system: EFI
• Maximum speed: 60 km/h
• Starter: Electric
• Gearbox: Automatic CVT L/H/N/R/P
• Drive: 4WD
• Differential lock: front

Chassis / Suspension / Brake

• Front suspension: Double A-arm
• Rear suspension: Double A-arm
• Shock absorber: Hydraulic, front & rear
• Brake system: Ventilated disc brakes
• Front tyres: AT 24x8-12
• Rear tyres: AT 24x10-12
• Rims: Steel

Dimensions & weight

• Dimensions (LxWxH): 2360 x 1200 x 1450 mm
• Wheelbase: 1490 mm
• Ground clearance: 275 mm
• Tank capacity: 18 L
• Unladen weight: 452 kg
• Passenger capacity: 2
• Wading depth: 510-560 mm

Instruments & equipment

• Instruments: 7" LCD screen
• Key start: Yes
• Handlebar protection: Yes
• Backrest: Yes
• Underride guard: Yes
• LED light: Yes
