Grease dispenser-portable 8 kg container-manually operated
€116.52
Description
Grease dispenser-portable 8 kg container-manually operated
Technical data
Container capacity (kg) 8
Container diameter (mm) 145
Reservoir height (mm) 380
Delivery media Lubricating greases NLGI 1-2
Delivery volume/stroke (cm³) 10
Delivery pressure up to (bar) 25
Grease delivery via hand pump
Manual filling, via removable pump
Delivery hose Armoured hose, 11 x 1500 mm
Surface treatment all steel parts are galvanised
Pump head impact-resistant die-cast zinc
Paint finish Container and lid window grey , silk matt, RAL 7040
Dimensions LxWxH (mm) 480 x 160 x 600
Weight (kg) 4 .9
Specification
Nozzle tube, bent, M 10 x 1, 150 mm
Sturdy handle
With foot grid
Pumping unit
High-pressure armoured hose, 11 x 1500 mm
Suction pipe with grease follower piston
Mouthpiece, 4 BA, M 10 x 1
Shut-off valve
Oil-resistant paint finish
