Fliegl square bale grab - Euro standard mount / hydraulic
€2,650.00
Free shipping
Available, delivery time: 2-5 days
Description
Fliegl square bale grab - Euro standard mount / hydraulic
Fliegl square bale tongs - Euro pick-up, hydraulic & film-protecting
TheFliegl square bale tongs grips, transports and stacks square bales safely and gently. Two powerful hydraulic cylinders ensure even pressure on both sides; the compact design facilitates precise stacking and work in confined spaces. Thanks toEuro standardisation the appliance is quickly ready for use on the front loader.
Your advantages at a glance
- Wide range of applications: Suitable for square bales withWidths from approx. 704-2,400 mm.
- Secure hold: 2 heavy-duty hydraulic cylinders reliably hold even heavy bales.
- Gentle handling: Optimised arm geometry forfilm-protecting Gripping and clean stacking.
- Compact on the road: Transport width approx. 1,350 mm - Ideal for yard & warehouse.
- Completely ready for connection: inclusiveHydraulic hoses and connectorsneeded1× double-acting connection.
Technical data
| Recording | Euronorm (front loader) |
| Bale sizes (width) | approx. 704-2,400 mm |
| Drive | hydraulic,2 cylinders |
| Fork length / height | 1,200 mm /490 mm |
| Transport width | approx. 1,350 mm |
| Hydraulic connection | 1× double-acting; hoses & plugsinclusive |
Technical data according to Fliegl Agro Centre product page; minor deviations possible depending on year of manufacture.
Typical areas of application
- Transport & stacking of square bales (straw, hay, silage)
- Yard and field logistics, storage and warehousing work
Scope of delivery
- FlieglSquare bale tongs -Euro intake
- Hydraulic hoses and plug-in couplings
- Operating & safety instructions
Notes & Safety
- Observe the lifting/tipping load and stability of the carrier vehicle; grip the bale in the centre.
- Check hydraulic connections before use; set clamping force moderately for film bales.
- Only work within the permissible working load and height; keep people away.
Why the Fliegl square bale tongs? Large gripping range, compact transport width and ready-to-connect Euro pick-up - the robust, economical professional solution for efficient square bale handling.
