Feed bunker / feed container 5 m³ - 400V / 5.5kW
€10,900.00
Free shipping
Available, delivery time: 1-2 weeks
Description
Feed bunker / feed container 5 m³ - 400V / 5.5kW
Feed hopper / feed container - 5 m³ - 400V / 5.5 kW
TheFeed hopper / feed container - 5 m³ is a robust and efficient solution for the Collection and supply of fuel chips, wood shavings, wood processing waste and other bulk materials. With a capacity of5 m³ it is ideal for continuous for continuous operation in wood and biomass processing and ensurescontinuous material flow for further processing.
Thanks to itssimple, functional construction and the powerful 5.5 kW geared motor the hopper offers long-lasting, trouble-free operation. An integrated control panel with frequency converter ensuresFlexible adjustment of the conveying capacity to the respective requirements. It is therefore ideally suited for industrial use in pellet and wood chip systems, heating plants or production lines.
Your advantages at a glance
- High efficiency: Reliable material feed with low energy consumption.
- Flexible: Processing of a wide variety of materials, depending on the properties.
- Precise control: Integrated frequency converter for adjustable delivery rate.
- Durable & robust: Stable chain drive for trouble-free continuous operation.
- Large capacity: 5 m³ capacity for continuous supply.
- Safe & reliable: High operational reliability even under load.
Typical areas of application
- Supply of fuel chips and wood shavings
- Promotion of wood waste in heating plants
- Feeding pellet mills or biomass plants
- Industrial wood and bulk goods processing
Technical data (feed hopper / feed container - 5 m³ - 400V / 5.5 kW)
| Product type | Feed hopper / feed container |
| Capacity | 5 m³ |
| Geared motor | 5.5 kW |
| Tension | 380-400 V |
| Drive | Chain drive |
| Dimensions (L × W × H) | 4600 × 1500 × 1800 mm |
| Weight | 840 kg |
| Control system | Including control panel with frequency inverter |
All technical specifications are based on manufacturer data. Deviations in performance and productivity are depend on the material and operating conditions.
Scope of delivery
- Feed hopper / feed container - 5 m³ - 400V / 5.5 kW
- Integrated control panel with frequency inverter
- Geared motor with chain drive
- Operating & safety instructions
Notes & Safety
- Only suitable for dry materials such as wood chips, wood shavings and similar bulk materials.
- Regular maintenance of the chain drive and motor recommended.
- Always check the control and safety systems before commissioning.
- Wear protective clothing (gloves, safety goggles, hearing protection) during operation.
Why the 5 m³ feed hopper? Because heLarge capacity, high efficiency and maximum operational reliability combined in one compact system - theoptimal solution for reliable material supply in the wood and biomass industry.
