Elmag Hydraulic Portal Press - 100T

Elmag electro-hydraulic portal press 100T - Maximum pressing force and precision for large workpieces

TheElmag electro-hydraulic portal press 100T was specially developed for theAligning, straightening and processing large sheets and structures developed. With a maximumPressing force of 100 tonnes and a robust, movable portal frame, it is the perfect solution for workshops, manufacturing companies and metalworking industries that demand maximum precision and performance.

Flexible design for maximum efficiency

ThePortal press 100T is characterised by asliding frame and a laterally adjustable hydraulic cylinder from. This allows access to every point of the workpiece surface - ideal for large-format components. TheManual displacement of the frame and cylinder head ensures maximum flexibility and precision for all straightening and fitting work.

Powerful hydraulics with double speed

With a powerful2,200 W electric motor and aelectrohydraulic drive the machine offers two drive speeds for different work requirements. The automatic piston reset saves time and enables an efficient workflow - ideal for continuous operation in production lines or workshops.

Elmag start-up service - With ELMAG® quality check

Before delivery, eachElmag portal press 100T comprehensively checked, adjusted and made fully operational by specialised technicians. TheELMAG® Start-Up Service guarantees the highest quality, safety and immediate readiness for use after delivery.

• Depreservation, degreasing and deprotection
• Assembly and adjustment of all components until ready for operation
• Oil filling and checking the hydraulic system
• Checking the electrics and safety components
• Test run at all performance levels
• 30-minute test run under full load
• Fine adjustment of machine parameters and tolerances

Note: When buying withELMAG® Start-Up Service the delivery time is extended by approx.2-3 weeksas each machine is individually tested and prepared.

Advantages of the Elmag electro-hydraulic portal press 100T

• MaximumPressing force of 100 tonnes for heavy-duty applications
• Movable frame and hydraulic cylinder - full machining freedom
• Precise work thanks todouble piston speed
• Automatic piston return for fast workflow
• Large passage (1,100 mm) for bulky workpieces
• Sturdy, torsion-resistant steel frame construction
• IntegratedOverload protection valve and pressure gauge
• Compatible with lubricating oils according toDIN 51517 - All approvals available for oils

Standard equipment

• Overload safety valve
• Press pressure gauge
• Switching valve up/down
• Chrome-plated cylinder piston
• Automatic piston return
• Hydraulic cylinder laterally adjustable
• Electro-hydraulic drive with two speeds
• Operating instructions / CE certification

Technical data - Elmag electro-hydraulic portal press 100T

Areas of application

• Straightening and aligning large sheets
• Embossing and punching work
• Toolmaking and mechanical engineering
• Repair of steel structures
• Industrial production and customised products

Conclusion

TheElmag electro-hydraulic portal press 100T offers maximum pressing force, precision and flexibility for professional metalworking. In combination with theELMAG® start-up service with quality check you get a tested, ready-to-use industrial hydraulic press that meets even the toughest requirements.

Elmag electro-hydraulic portal press 100T - 100 tonnes of force, maximum precision and proven ELMAG® quality for your production.
