Danfoss / White hydraulic orbit motor OML 8cm3 / Ø16mm

Danfoss

€272.44

Prices exclude VAT.

Free shipping

Available, delivery time: 1-3 days

Product number: SW10004

Brand	White
Areas of application	Applications with high torque and low speeds Blower and brush drives Conveyor belts on harvesters
Properties	Robust Compact High radial and axial load capacity of the shaft
Technical information	Without leakage oil connection Rotor design Wide plain shaft bearing Belongs to the series of small orbital motors
Advantages	Continuous operation at medium pressure Short-term operation at high pressure
Number of mounting holes	4
Shaft type	Straight parallel
Shaft diameter	16 mm
Shaft thread diameter	M5
Thread type Shaft	Metric
Swallowing volume	8 cm³/rev
Max. Continuous torque	7 N-m
Seal type	Standard
Max. Continuous operating pressure	70 cash
Max. intermittent operating pressure	125 cash
Max. Peak pressure	140 cash
Max. Flow rate	16 l/min
Max. Speed	2000 rpm
Min. speed	50 rpm
Thread diameter of suction connection	1/4 Inch
Thread type Main connection	G
L1Rotor length	4,1 mm
Max. power	1,1 kW
L1Housing length	102,5 mm
Connection	1/4" BSP
