Compressor Battioni Paggani MEC8000H
€1,788.00
Free shipping
Available, delivery time: 2-3 days
Zubehör
Available, delivery time: 1-3 days
Available, delivery time: 1-3 days
Available, delivery time: 1-3 days
Ersatzteile
Available, delivery time: 1-3 days
Available, delivery time: 1-3 days
Available, delivery time: 1-3 days
Available, delivery time: 1-3 days
Compressor Battioni Paggani MEC8000H
| Special features |
|
|
|---|---|---|
| Areas of application |
These vacuum pumps with vanes are mainly used in the agricultural sector for filling and emptying slurry tanks
|
|
| Properties |
These pumps can generate both positive and negative pressure
|
|
| Technical information |
|
|
| Advantages |
As B.P. pumps are tested, checked and packaged with the utmost care, one hundred per cent trouble-free start-up is guaranteed
|
|
| Nominal volume flow |
8100 l/min
|
|
| Drive type |
Hydraulics
|
|
| Direction of rotation |
Clockwise rotation (CW)
|
|
| Ballast air injection system |
No
|
|
| Scope of delivery |
|
|
| Lubrication system type |
Manual
|
|
| Slat type |
Standard
|
|
| Collision protection system |
No
|
|
| Max. Vacuum |
0.9 bar
|
|
| Max. relative pressure |
1.5 bar
|
|
| Power requirement for max. pressure |
22 kW
|
|
| Power requirement for max. vacuum |
15 kW
|
|
| Hydraulic motor, required capacity |
63.5 l/min
|
|
| DDiameter of the hose connection |
80 mm
|
|
| Diameter of safety valve connection |
1-1/2 inch
|
|
| ATotal length |
735 mm
|
|
| BTotal width |
410 mm
|
|
| CHeight |
597 mm
|
|
