Cebora plasma cutter - cutting cut max. 15mm / cutting thickness steel 0-8mm
€2,050.00
Free shipping
Available, delivery time: 2-5 days
Description
Cebora plasma cutter - cutting cut max. 15mm / cutting thickness steel 0-8mm
CEBORA Power Plasma 3035/M - compact 30 A plasma cutter with HF ignition & auto-voltage
ThePower Plasma 3035/M is a mobileInverter plasma cutter for workshop, assembly and bodywork. With only13 kg Weight,High-frequency ignition (HF) andAutomatic mains voltage detection 115/230 V it delivers clean cuts in steel, stainless steel & aluminium.Pilot sheet and"Pilot self-restart" ensure reliable cuts even on grids, painted or coated materials. Operated with compressed air - for maximum cutting quality also withNitrogen.
Your advantages at a glance
- Powerful & precise: Recommended cutting thicknessup to 8 mm, maximum12 mm, separating cut15 mm (steel).
- Simply connect: single-phase115/230 V with automatic switchover; slow-blow fuse32 A (115 V) /16 A (230 V).
- Work consistently: Duty cycle22 A @ 100 %,25 A @ 60 %,30 A @ 35 % (IEC 60974-1).
- Convenience when cutting: Pilot sheet operation &Self-Restart for interruptions (grilles, spot-welded sheets).
- Low air requirement: only60 l/min at 3.5 bar - Ideal for mobile applications.
Typical applications
- Car body & vehicle construction, locksmithery, maintenance
- Assembly inserts: Cutting of sheet metal, profiles, grids
- Stainless steel/aluminium reworking, cutting of spot-welded sheet metal
Technical data
| Net | 115/230 V, 50/60 Hz,Auto voltage (±15 % / -20 %) |
| Fuse (slow-blow) | 32 A (115 V) /16 A (230 V) |
| Current range | 5-30 A, stepless |
| Duty cycle (10 min / 40 °C) | 30 A 35 % -25 A 60 % -22 A 100 % |
| Recommended cut / max. / separating cut (steel) | 8 mm /12 mm /15 mm |
| Ignition | HF ignition -Pilot sheet -Pilot self-restart |
| Process gas | Compressed air (qualitatively dry) - optionalNitrogen |
| Air requirement | 60 l/min at 3.5 bar |
| Protection class | IP23S |
| Dimensions (L × W × H) | 503 × 175 × 400 mm |
| Weight | 13 kg |
| Generator operation | suitable, recommendation≥ 6 kVA |
Scope of delivery
- CEBORA Power Plasma 3035/M (Art. 279)
- CEBORA CP40 MAR Hand burner,4 m
- Earth cable with terminal,4 m
- Integrated pressure regulator - Operating instructions
Accessories / Options
- CP40 DAR Burner forautomatic/drawn Operation + interface kit (CNC/cutting tables)
- Consumables sets (nozzle, electrode, swirl ring)
- Compressed air treatment: Filter/dehumidifier
Notes
- For best results, use dry, clean compressed air; optional for stainless steel/aluminiumN₂.
- Wear PPE (eye/hearing/breathing/hand protection); make a ground connection near the interface.
Why the 3035/M? Powerful 30 A cut in a 13 kg housing, HF ignition with pilot arc and 115/230 V auto-voltage - the professional, mobile solution for precise cutting in the workshop and on the move.
