Bucket conveyor / bucket elevator 2600mm - 400V / 1.5kW
€3,950.00
Free shipping
Available, delivery time: 5-10 Tage
Description
Bucket conveyor / bucket elevator 2600mm - 400V / 1.5kW
Bucket conveyor / bucket elevator 2600mm - 400V / 1.5kW
The bucket conveyor is an advanced device for theVertical transport of grain, seed and other bulk goods. With a delivery height of 2.6 metres, the device is perfect forAgricultural businesses, processing companies and silos. It offers a high conveying capacity with a compact design.
Areas of application:
- Agriculture (grain, maize, animal feed)
- Food industry
- Storage technology and bulk goods logistics
- Material conveying in mills and mixing plants
Advantages of the cup conveyor:
- High conveying capacity: up to 10 t/h for wheat grain
- Compact design - Easy to integrate and relocate
- Reliable drive with 1.5 kW motor power (400V)
- Low-maintenance operation due to stable construction
- Conveys at height - Ideal for vertical processes
Technical data:
- Total height: 2600 mm
- Motor power: 1.5 kW
- Voltage: 380-400 V
- Conveying capacity: up to 10 tonnes per hour
- Belt speed: 2 m/s
- Drive drum: Ø 294 mm, 124 rpm
- Belt width: 150 mm, thickness: 4 mm
- Bucket spacing: 204 mm
- Bucket size: 125 x 110 mm
- Conveying head: 963 x 427 x 685 mm
The bucket elevator conveyor from Brander offers aEfficient, space-saving and reliable solution for internal material flow. Ideal for modern agricultural and industrial applications.
