Bale wrapper 90–160 cm | stationary & hydraulic | for round bales from 30 hp tractor power
€2,150.00
Description
Bale wrapper 90–160 cm | stationary & hydraulic | for round bales from 30 hp tractor power
Bale wrapper for round bales 90-160 cm - stationary & hydraulically driven from 30 hp tractor power
TheBale wrapper for round bales with a diameter of 90-160 cm is a robust, stationary device for the professional preparation ofHay silage for the year-round feeding of breeding animals. Thanks to its durable construction, hydraulic drive and simple operation, this wrapper is ideal for farms that strive for the highest quality and efficiency in feed production.
Powerful, stationary silage winder
This model is designed for stationary use and works reliably with aTractor power from 30 hp. The drive is operated via theHydraulic system of the tractor (single-acting with free return or double-acting). An integratedOverload valve protects the hydraulic system from damage, especially when starting and braking.
Efficient wrapping technology with selectable film width
The bale wrapper supports two working modes: - with500 mm film width (24 windings) - with750 mm film width (16 wraps) This ensures flexibility for different bale sizes and material requirements. An integratedRevolution counter ensures precise control during the wrapping process.
Robust construction - developed for durability
The bale wrapper impresses with itsSolid, powder-coated steel construction and is designed for tough daily use. The quality features include
- ✔Stable and durable construction with precision-cut steel gearbox
- ✔Corrosion protection through powder coating
- ✔Moulded aluminium castors for perfect film guidance
- ✔Steel deflector for secure bale retention
- ✔Valve for smooth starting and stopping
- ✔Brand warehouse for a long service life
- ✔Hydraulic lines andWinding counter Included in the scope of delivery
Easy handling and safe tipping
Once the wrapping process is complete, the bale can be easily and safelydumped become. The device is intuitive to operate, which makes the bale wrapper ideal for less experienced users.
Technical data - Stationary bale wrapper 90-160 cm
| Technical specification | Value |
|---|---|
| Bale diameter | 90 - 160 cm |
| Power requirement | from 30 hp |
| Film width | 500 mm or 750 mm |
| Windings | 24 at 500 mm / 16 at 750 mm |
| Drive | Hydraulic via tractor system (EW + free return or DW) |
| Start/stop system | Hydraulic valve with overload protection |
| Revolution counter | Integrated |
| Construction | Steel, powder-coated |
| Dead weight | approx. 400 kg |
| Tilt function | Manual after wrapping process |
Advantages at a glance
- For bales with a diameter of 90-160 cm
- Hydraulic drive via tractor
- ✔ Integrated overload valve to protect the hydraulic system
- ✔ Powder-coated, durable steel construction
- ✔ Precise winding control with revolution counter
- ✔ Two film widths (500 / 750 mm) possible
- ✔ Very easy handling and maintenance
- ✔ Including hydraulic lines and winding counter
Areas of application
- ✔ Agricultural holdings with livestock farming
- Silage production for breeding animals and dairy farming
- ✔ Farms with seasonal or year-round fodder storage
Conclusion
TheBale wrapper for 90-160 cm round bales is the perfect solution for farmers whoReliability, simple operation andLong service life search. With its robust construction, precise hydraulic control and flexibility in film selection, it guaranteesEfficient and safe silage wrapping over many years.
Stationary bale wrapper 90-160 cm - hydraulic round bale wrapper for hay silage, with wrapping counter, tipping function and robust powder coating. Ideal for farmers and forage farms with a tractor power of 30 hp or more.
